VERTIV PSA 1000VA (600W) 230V UPS PSA1000MT3-230U

Advantages

-Person pleasant LED show for simple operation

-Mixture of battery-backed and surge-only sockets to adapt to various kinds of hundreds and necessities

-USB communications/shutdown software program and cable included for plug and play use

-Person replaceable batteries to maximise preliminary funding

Options

-Gives a number of battery backed and surge protected sockets

-Liebert PSA offers 5 or extra minutes of battery backup (relying on load stage)

-Protects datalines

-Totally RoHS compliant

Model Number PSA1000MT3-230U
Capacity:       VA/W  1000 / 600
Net Weight:    kg  9.5
Shipping Weight: kg 10.7
Dimensions: W x D x H, mm  147 x 360 x 234
On-Line Mains Voltage: 160-287VAC
On-Line Frequency:  50/60Hz ±5Hz
Output Voltage (Mains Normal):    Typical 185-252VAC
Output Voltage (Battery Operation):     230VAC ±5>#br###On-Battery Wave Form:   Stepped Sinewave
Battery Type – VDC x Ah – Quantity:    12V x 7.2Ah x 2
Typical Recharge Time:   6-8 hours to 90>#br###Battery Run Time* (Full load):  3-5 minutes
Battery Run Time* (Half load):  10-13 minutes
Audible and Visual:    Audible alarm / LED
Backup Sockets:    IEC 320 C13 (6)
Surge Sockets:       IEC 320 C13 (2)
Operating Temperature:  °C 0 to 40
Storage Temperature: °C -15 to 40
Operating / Storage Relative Humidity:    0%-90%, non-condensing
EMI Classification:            Class B
Agency:
Safety:  IEC62040-1-1
Transportation:  ISTA Procedure 1A Certification
Warranty:  2 years standard (+ 1 year warranty extension available).
Packaging: User Manual on CD, Software CD, USB cable, Safety Instruction Sheet, Environment protection sheet, (2) IEC output cables for 500/650VA,
(3) IEC output cables for 1000/1500 VA

Runing times                           (in minutes):

LOAD (WATTS):                      PSA1000MT3-230U

Load (VA):                                   1000VA

200                     :                          50
400                      :                         18
600                       :                        10
800                        :                        7
1000                       :                       4
1200                        :                      –
1400                         :                     –
