VERTIV PSP 500VA (300W) 230V UPS PSP500MT3-230U

Brand: Vertiv

Advantages

-Liebert® PSP has a compact design ultimate for desktop purposes

-Person pleasant LED show to make interplay with UPS simpler

-Person replaceable batteries to maximise preliminary funding

-Ample backup time to grant orderly OS shutdown in case of energy failure

-Package deal full with every thing is required for plug-and-play use

Options

-Battery-backed sockets and a surge solely socket

-Shutdown software program and USB cable included

-Protects datalines

-Totally RoHS Compliant

Model Number PSP500MT3-230U
Capacity (VA / W): 500 / 300
Net Weight (kg): 3.9
Shipping Weight (kg): 4.8
Dimensions: W x D x H (mm): 87 x 215 x 251
On-Line Mains Voltage: 160 to 287VAC
On-Line Frequency: 50 / 60Hz ± 5Hz
Output Voltage (Mains Normal): Typical 160 to 287VAC
Output Voltage (Battery Operation): 230VAC ± 5%
On-Battery Wave Form: Stepped Sinewave
Battery Type: VDC x Ah x Quantity 12V x 7.2 Ah x 1
Typical Recharge Time: 6 to 8hr to 90%
Audible and Visual: Audible alarm / LED
Back-up Sockets: IEC 320 C13 (3)
Surge Sockets: IEC 320 C13 (1)
Operating Temperature: (°C) 0 to 40
Storage Temperature: (°C) -15 to 40
Operating / Storage Relative Humidity: 0% to 90%, non-condensing
EMI Classifi: cation Class B
Agency: Approvals
Safety: IEC / EN / AS 62040-1-1
EMC:
EN 62040-2:2005 Class B
IEC 61000-4-2 Electrostatic Discharge
IEC 61000-4-3 Radiated E-RFI Fields
IEC 61000-4-4 Fast F Transients
IEC 61000-4-5 Surges / Lightning
IEC 61000-4-6 Conducted RFI
Transportation: ISTA Procedure 1A Certifi cation
Packaging:
User Manual on CD, Software CD,
USB Cable Safety Instruction Sheet,
Environment Protection Sheet

Runtime (in minutes):
Load(W)   PSP500MT3-230
50      :             55
100     :            18
150      :           11
200       :           8
250        :          5
300         :         3
350          :        –
