VERTIV PSA1500VA (900W) 230V UPS PSA1500MT3-230U

Advantages

-Person pleasant LED show for simple operation

-Mixture of battery-backed and surge-only sockets to adapt to various kinds of hundreds and necessities

-USB communications/shutdown software program and cable included for plug and play use

-Person replaceable batteries to maximise preliminary funding

Options

-Affords a number of battery backed and surge protected sockets

-Liebert PSA gives 5 or extra minutes of battery backup (relying on load degree)

-Protects datalines

-Totally RoHS compliant

Model Number:          PSA1500MT3-120U
Capacity (VA/W):          1500/900
Net Weight, lb. (kg):          27.8 (12.6)
Shipping Weight, lb. (kg):  30.0 (13.6)
Dimensions – W x D x H, in. (mm):  147 x 360 x 234
On-Line Input Voltage:   84-140VAC
On-Line Frequency:       50/60Hz ±5Hz
Output Voltage (Mains Normal): Typical 97-129VAC
Output Voltage (Battery Operation): 120VAC ±5%
On-Battery Wave Form: Stepped sinewave
Battery Type – VDC x Ah x Quantity: 12V x 9Ah x 2
Typical Recharge Time: 6-8 hours to 90%
Battery Run Time*: – Full Load 6 minutes
Battery Run Time*: – Half Load 12-13 minutes
Audible and Visual:   Audible alarm / LED
Backup Outlets: NEMA 5-15R (6)
Surge Outlets:  NEMA 5-15R (2)
Operating Temperature: °F (°C) 32 to 104 (0 to 40)
Storage Temperature:     °F (°C) 5 to 104 (-15 to 40)
Operating / Storage Relative Humidity: 0%-90%, non-condensing
EMI Classification FCC Part 15:         Class B
Agency:
Safety:  UL 1778, c-UL Listed
Transportation:  ISTA Procedure 1A Certification

Runtime:                      (in minutes)
Load (VA):                         1500VA
200              :                        65
400               :                       25
600                :                      14
800                 :                     10
1000                :                     7
1200                 :                    5
1400                  :                   4
